SEGGER J-LINK PLUS

J-Link PLUS / J-Link PLUS Compact

JTAG/SWD debug probe with USB interface. Based on a 32-bit RISC CPU, it can communicate at high speed with the supported target CPUs. J-Link is used around the world in tens of thousand places for development and production (flash programming) purposes.

J-Link Debug Probes ➦

JTAG/SWD debug probe with USB interface

J-Link PLUS is a USB powered JTAG debug probe supporting a large number of CPU cores. Based on a 32-bit RISC CPU, it can communicate at high speed with the supported target CPUs. J-Link is used around the world in tens of thousand places for development and production (flash programming) purposes.

J-Link PLUS is available in two form factors with identical function: J-Link PLUS and J-Link PLUS Compact.

The J-Link debug probes are supported by all major IDEs including Eclipse, GDB-based IDEs and SEGGER Embedded Studio. For a complete list, please refer to Supported IDEs. Including all models, more than 500,000 J-Links have been shipped so far, making J-Link probably the most popular debug probe for ARM cores and the de-facto standard.

Media

videoPreview.jpg videoPreview.jpg
SEGGER J-Link Flash Breakpoint IntroductionSEGGER J-Flash Introduction


Licensing

J-Link PLUS comes with licenses for all J-Link related SEGGER software products:

J-Link Unlimited Flash Breakpoints, J-Link RDI / RDDI, J-Flash providing the optimum debugging experience for professional developers.

  • Comes with integrated licenses for: Unlimited breakpoints in flash memory (Unlimited Flash Breakpoints), RDI / RDDI and J-Flash
  • Superset of J-Link BASE [More..]
  • Supports a broad range of microcontrollers [More..]
  • Supports direct download into RAM and flash memory
  • Download speed up to 1 MByte/s
  • Supports unlimited breakpoints in flash memory [More..]
  • Multiple CPUs supported—8051, PIC32, RX, ARM7/9/11, Cortex-M/R/A, RISC-V [More..]
  • Free software updates
  • Built-in VCOM functionality [More..]
SpecificationValue
Supported OSMicrosoft Windows 2000, XP, 2003, Vista, 7 and newer (32 bit and 64 bit versions)
Linux
macOS 10.5 and higher
Electromagnetic compatibility (EMC)EN 55022, EN 55024
Operating temperature+5°C ... +60°C
Storage temperature-20°C ... +65 °C
Relative humidity (non-condensing)Max. 90% rH
Mechanical
Size standard housing (without cables)100mm x 53mm x 27mm
Weight standard housing (without cables)70g
Size compact device (without cables)47mm x 40mm x 14mm
Weight compact device (without cables)20g
Available Interfaces
USB interfaceUSB 2.0 (Hi-Speed)
Target interfaceJTAG/SWD 20-pin (adapters available)
JTAG/SWD Interface, Electrical
Power supplyUSB powered Max. 50mA + Target Supply current.
Target interface voltage (VIF)1.2V ... 5V
Current drawn from target voltage sense pin (VTRef)< 25µA
Target supply voltage5V (derived from USB voltage)
Target supply currentMax. 300mA
Reset typeOpen drain. Can be pulled low or tristated
Reset low level output voltage (VOL)VOL <= 10% of VIF
For the whole target voltage range (1.2V <= VIF <= 5V)
LOW level input voltage (VIL)VIL <= 40% of VIF
HIGH level input voltage (VIH)VIH >= 60% of VIF
For 1.2V >= VIF <= 3.6V
LOW level output voltage (VOL) with a load of 10 kOhmVOL <= 20% of VIF
HIGH level output voltage (VOH) with a load of 10 kOhmVOH >= 80% of VIF
For 3.6 <= VIF <= 5V
LOW level output voltage (VOL) with a load of 10 kOhmVOL <= 20% of VIF
HIGH level output voltage (VOH) with a load of 10 kOhmVOH >= 80% of VIF
JTAG/SWD Interface, Timing
Target interface speedMax. 15 MHz
SWO sampling frequencyMax. 30 MHz
Data input rise time (Trdi)Tfdi <= 20ns
Data output rise time (Trdo)Trdo <= 10ns
Data output fall time (Tfdo)Tfdo <= 10ns
Clock rise time (Trc)Trc <= 3ns
Clock fall time (Tfc)Trc <= 3ns
